Audio-Technica AT33x Series Dual Moving Coil Stereo Cartridge - AT33XMLD

Product Details
Audio-Technica AT33XMLD AT33x Series Dual Moving Coil Stereo Cartridge
The Audio-Technica AT33XMLD AT33x Series dual moving coil stereo cartridge pairs a nude Microlinear stylus with a tapered duralumin cantilever for precise groove tracking and detailed 20 to 42,000 Hz response. Independent PCOCC left- and right-channel coils provide 27 dB separation, while a neodymium magnet and permendur yoke support responsive 0.4 mV output. A die-cast zinc, aluminum and high-rigidity polymer body disperses resonance, and M2.6 threaded holes make two-screw mounting easier, especially on an integrated tonearm.
Its warm, full-bodied balance gives instruments and voices lifelike mid-to-low-frequency expression, making this turntable cartridge especially well suited to rock and jazz records from the 1950s, '60s and '70s.
Key Features
Warm, Full-Bodied Audio
The Audio-Technica AT33XMLD is tuned to reveal fine detail without losing the richness associated with classic analog playback. Its expressive mid-to-low-frequency character brings satisfying weight to instruments and the human voice, with a presentation designed to complement rock and jazz recordings, particularly albums from the 1950s, '60s and '70s.
Nude Microlinear Stylus and Duralumin Cantilever
The nude Microlinear stylus follows intricate groove information with high accuracy, helping uncover subtle musical textures. Its high-hardness duralumin tapered pipe cantilever improves control at higher frequencies, while the firm connection between the cantilever, stylus and suspension supports stable, nuanced reproduction.
27 dB Channel Separation and PCOCC Coils
Separate moving coils for the left and right channels keep stereo information distinct, delivering 27 dB channel separation at 1 kHz. Positioned at the cantilever's fulcrum, the PCOCC coils create a pure, smooth path for each channel's signal.
Efficient Magnetic System
A neodymium magnet works with a permendur yoke to create a strong magnetic field and maximize power-generation efficiency. The result is responsive, high-resolution playback from the cartridge's 0.4 mV output.
Resonance-Controlled Composite Body
Die-cast zinc, aluminum and high-rigidity polymer are arranged throughout the cartridge body to reduce and distribute resonance instead of allowing one frequency range to dominate. Dense zinc at the base further suppresses unwanted vibration, reinforcing balanced sound and greater expressiveness through the mid-to-low range.
Suspension Designed for Tonearm Versatility
A newly developed mechanism uses piano wire with a redesigned rubber damper to improve tracking accuracy. Its slightly lower dynamic compliance gives the sound greater substance and allows the cartridge to work with a variety of tonearms.
Easy Two-Screw Threaded Mounting
M2.6 threaded holes let the AT33XMLD attach with only two screws during a turntable setup. This arrangement is especially convenient when the headshell is integrated into the tonearm.
Gold-Plated Terminals and Japanese Craftsmanship
Thick gold plating on the terminal pins reduces contact resistance at the cartridge connection. Each AT33XMLD is crafted and hand-finished by artisans in Japan.
Features
Audio-Technica AT33XMLD AT33x Series Design
Refreshes the moving coil cartridge platform with upgraded materials and suspension engineering.
Warm, Full-Bodied Audio
Brings richness and detail to instruments and voices on rock and jazz records, especially recordings from the 1950s, '60s and '70s.
Nude Microlinear Stylus
Reads fine groove modulations for precise, nuanced record playback.
Duralumin Tapered Pipe Cantilever
Provides high rigidity and refined high-frequency control.
20 to 42,000 Hz Frequency Response
Reproduces detail across a wide audio spectrum.
Independent Dual Moving Coils
Maintains distinct left and right signals with 27 dB channel separation at 1 kHz.
PCOCC Coil Conductors
Promote clean, smooth signal transmission from both stereo channels.
Neodymium Magnet and Permendur Yoke
Create an efficient magnetic circuit for responsive high-resolution output.
Three-Material Composite Body
Combines zinc, aluminum and high-rigidity polymer to distribute resonance evenly.
Die-Cast Zinc Base
Controls unwanted vibration and strengthens mid-to-low-frequency expression.
Piano-Wire Suspension and Rubber Damper
Support accurate tracking and compatibility with a variety of tonearms.
M2.6 Threaded Mounting Holes
Secure the cartridge with two screws for easier headshell installation.
Thick Gold-Plated Terminal Pins
Reduce contact resistance at the electrical connection.
Crafted and Hand-Finished in Japan
Reflects artisan assembly and finishing for every cartridge.
Moving Coil Exchange Program
Provides a fee-based service option for the AT33XMLD stylus assembly.1
Footnotes
1 The AT33XMLD stylus assembly is not field-replaceable. Audio-Technica offers a fee-based Moving Coil Exchange Program to service the moving coil cartridge.
Read More
California customers
Proposition 65 WARNING
WARNING: Cancer and Reproductive Harm

Specifications
General
Color
Gold | Black
Type
Cartridge
Stylus
Nude Microlinear
Quantity
1
Frequency Response
20 - 42,000Hz
Channel Separation
27 dB (1 kHz)
Vertical Tracking Angle
19 degrees
Tracking Force
1.8 to 2.2 g (2.0 g standard)
In the Box
1 x AT33xMLD Cartridge, 1 x Non-Magnetic Screwdriver, 1 x Brush, 2 x Washers, 2 x M2.6 Cartridge Installation Screws (8.0 mm (0.31 in)), 2 x M2.6 Cartridge Installation Screws (10.0 mm (0.39 in)), 2 x M2.6 Cartridge Installation Screws (13.0 mm (0.51 in)), 1 x Protector
Made In
Japan
Recommended Load
>= 100 Ohm
Impedance
12 ohms (1 kHz)
Approximate Weight
Package Weight (lbs)
0.02
